Blue Diamond X87-721 - MaxiBlue 3.7 GPH Condensate Pump and Reservoir, 230V

The Blue Diamond X87-721 MaxiBlue Condensate Pump is a high-performance condensate removal solution designed for ductless mini-split systems, air conditioners, refrigeration equipment, and other HVAC applications. Operating on 230V power, this pump delivers condensate removal rates up to 3.7 GPH while providing quiet, reliable performance. The included reservoir automatically activates the pump when condensate reaches the appropriate level, helping prevent overflow and water damage. Its compact design allows for flexible installation in tight spaces, making it an excellent choice for residential and commercial HVAC systems.

Features

• Manufacturer: Blue Diamond
• Part Number: X87-721
• UPC: 811798030205
• MaxiBlue condensate pump with reservoir
• 208V - 230V operation
• Pumps up to 3.7 GPH of condensate
• Ideal for ductless mini-split systems, air conditioners, refrigeration equipment, and other HVAC applications
• Integrated reservoir automatically controls pump operation
• Quiet operation for residential and commercial installations
• Compact design fits in tight installation spaces
• Helps prevent condensate overflow and water damage
• Reliable, long-life diaphragm pump technology
• Genuine Blue Diamond condensate pump assembly

Designed for high humidity environments and with high performance, the MaxiBlue is ideally suited for mid range air conditioning systems. Its exceptional reliability is backed by a multi year warranty and with class leading performance/suction lift, the MaxiBlue is ideal for installations in environments that are both demanding and expensive to access for maintenance.

What is the MaxiBlue?

The MAXIBLUE is a small yet powerful pump, using the same patented sensing technology as the rest of the range. The pump is totally self-priming, and offers advertised flow even in high lift and high head applications, a unique feature in the condensate removal pump market. Designed for high humidity environments, the MAXIBLUE only senses when water is present, offering an energy efficient drainage solution for condensate removal. The pump can be mounted in any orientation and is exceptionally quiet with no vibration, making it ideal for installations where low noise levels are key.

Performance

• Max Flow: 3.7 GPH
• Max Head: 23 ft
• Max Lift: 16.5 ft
• The MAXIBLUE can be mounted in any orientation up to 16.5FT away from the A.C unit.
