Rain Bird ESP-LXD - 50 Station 2-Wire Decoder Controller - Expandable to 200 Stations

The result of 40 years of expertise and thousands of installed units, the ESP-LXD is a modern, reliable, two-wire decoder controller. With a large display, simple-to-use dial, English/Spanish language support, and extra simple programming, the ESP-LXD dramatically cuts installation and troubleshooting time for even up to the most extensive operations.

Features

Two-wire run lengths up to 2.5 miles (4km)
Two-wire decoder-based irrigation reduces wire and simplifies troubleshooting
Four independent programs with capability to overlap
Control well, boost, fertigation, and other pumps
Supports up to 5 master valves, 5 flow sensors, 4 weather sensors and a variety of upgrades
Same easy-to-use programming interface as other ESP series controllers
6 user-selectable languages including English, Spanish, French, Italian, German & Portuguese
Up to 96-hours of continuous runtime
Up to 8 simultaneous stations
50 station two-wire decoder controller standard, expandable to 200 stations with optional 75-station expansion module
Upgradeable to remote access with ClimateMinder
UV-resistant, outdoor-rated plasting locking wall-mountable case
Built-in flow management software
Rain Bird residential valves (CP,DV and JTV series) are not compatible with ESP-LXD decoders. Use Rain Bird commercial valves (PGA, PEB, GB, EFB-CP and BPE series)

Specifications

Station timing: up to 96 hours of continuous runtime
Program level and global Monthly Seasonal Adjust: 0% to 300%
4 independent programs (ABCD); ABC programs stack, ABCD overlap
8 start times per program
Manual station, program, test program
Input required: 120 VAC ± 10%, 60Hz
Power back-up: Lithium coin-cell battery maintains time and date while nonvolatile memory maintains the schedule
Multi-valve station capacity: up to 2 solenoid valves per station; simultaneous operation of up to eight solenoids and/or master valves
Dimensions: 14.32" W x 12.69" H x 5.50" D

IEZR800050
