LF4855038 - ProPEX LF Brass Angle Stop Valve (full port), 1/2" PEX - Engineered Polymer (EP)

In stock
SKU: LF4855038
Regular price $9.99

Free Shipping on all orders over $79.99!

Most orders ship same day and deliver in 2-3 business days!

Freight deliveries require extra time to arrange pickup & delivery.

Call Us! Have questions or want to order by phone? (800) 468 5997

Customer Reviews

Based on 1 review
Jake C.

Works great for a dishwasher shutoff or toilet shutoff

Angle Stop Valve is used for point-of-use shutoff at the fixture.

ProPEX® Lead-free Full-port Brass Stop Valve is quarter-turn, chrome-plated and available in either angle or straight-stop configurations.This stop valve is used for point-of-use shut-off at the fixture. This stop valve connects ½" AquaPEX® tubing to 3/8" O.D. risers.

Material: Chrome-plated C69300 Brass
Maximum Temperature (no pressure): 140°F (60°C)
Maximum Working Temperature/Pressure: 10 to 12 seconds/3 to 4 seconds
End Switch Rating: 125 psi

Installation: Install the stop valve according to your local building code. Do not dismantle. Refer to the AquaPEX Professional Plumbing Installation Handbook or Uponor Radiant Floor Installation Handbook for additional information.

Standards: CSA B137.5 and B125; ASTM F877; ASTM F1960; ASME A112.18.1

Codes: IPC; UPC; NSPC; NPC of Canada

Listings: ANSI/NSF 14- and 61-certified; U.P. Code, Annex G

Related Applications: PEX-a Plumbing Systems
Radiant Heating and Cooling Systems
Snow and Ice Melting Systems
Permafrost Protection Systems
Turf Conditioning Systems
