Axiom RIA10-1SAA - SF/MF Series System Feeder Low Level Alarm Panel

Only 4 left
SKU: RIA10-1SAA
Regular price $585.00

Free Shipping on all orders over $79.99!

Most orders ship same day. Delivery in 2-3 business days!

Call Us! Have questions or want to order by phone? (800) 468 5997

Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

RIA10 Brochure

Installation Instructions

Specification Sheet

Axiom RIA10-1SAA - SF/MF Series System Feeder Low Level Alarm Panel

On a low-level condition the RIA10-1-SAA Alarm Panel will be disable the system feeder, audible alarm will sound and a set of dry contacts will close for remote indication to a DCS.

Alarm panel shall incorporate a power supply cord, pump/alarm relay, power on and alarm indicating lights, alarm buzzer, test switch, silence/off switch, and receptacle for SF100 power supply cord. On a low-level condition the SF100 will be disabled, the alarm will sound and a set of dry contacts will close (for remote indication if connected to a DCS). The alarm buzzer may be disconnected by removing a jumper in the alarm circuit.

Features

  • Provides Audible & Visual LED notification of a low-level condition inside system feeder
  • On low-level condition the power supply used for the svster feeder power will be disabled
  • Easily test the panel operation at the push of a button
  • Audible Alarm can be silenced
  • Includes a set of dry contacts for third-party notification
  • All units plug into any standard 115 VAC outlet
  • Panel is UL listed

Specifications

  • Electrical Rating Motors: 1/4 hp at 115 Volts/230 Volts
  • Cable: Neoprene, Type SJOW No. 16/2 (7.6 mm Dia.)
  • Temperature: 140 Degrees F
  • Panel Dimensions: 6" x 4.75" x 2.25"
