Watts 0009431 -1-1/2" Lead Free Water Pressure Reducing Valve, NPT Female Union x NPT Female

This 1 1/2 IN lead free water pressure reducing valve is designed to reduce incoming water pressure to protect plumbing systems and reduce water consumption for commercial, industrial and residential applications. The easy maintenance assembly consists of a replaceable seat module, NPT threaded female union inlet by NPT female outlet and a bypass feature to control thermal expansion pressure. The temperature range is 33 to 180 degrees F (0.5 to 82 degrees C). Suitable for up to 300 psi (20.7 bar), the pressure range can be adjusted from 25 to 75 psi (172 to 517 kPa) with the standard setting at 50 psi (345 kPa).

Features

• Sealed spring cage with stainless steel cage screws
• Integral stainless steel strainer removable for cleaning
• Replaceable seat module
• Lead free construction

Specifications

• Adjustable Reduced Pressure Range: 25 to 75
• Adjustable Reduced Pressure Range-BAR: 1.7 to 5.2
• Body Material: Lead Free Copper Silicon Alloy
• Brand: Watts
• Buy American Act Compliant: YES
• Corrosion Resistant Coating: No
• Disc Material: EPDM
• EAN: 098268331868
• Gauge Option: No Gauge
• Inlet Connection Size: 1 1/2 IN
• Inlet Connection Type: Union Female Threaded
• Inlet Thread Type: NPT
• Lead Free: YES
• Maximum Operating Temperature-Fahrenheit: 180
• Maximum Working Pressure-BAR: 20.70
• Maximum Working Pressure-PSI: 300
• Minimum Temperature-Fahrenheit: 33
• Outlet Connection Size: 1 1/2 IN
• Outlet Connection Type: Female Threaded
• Outlet Thread Type: NPT
• Part Number: 0009431
• Series: LF25AUB-Z3
• Standard Reduced Pressure Setting-BAR: 3.40
• Standard Reduced Pressure Setting-PSI: 50
• Strainer: Yes
• Strainer Material: Stainless Steel
• Thermal Expansion Bypass: Yes
• Valve Style: Standard
