Sloan 3325451 - EBV-129-A-U G2 Electronic Module for Urinal Flushometers

The Sloan 3325451 EBV-129-A-U is a G2 Optima Plus electronic module designed specifically for urinal applications. It serves as a replacement part for Sloan G2 and ECOS series urinal flushometers, ensuring reliable, touch-free operation in commercial restroom settings.

This electronic module utilizes an infrared sensor to detect user presence, initiating a flush cycle once the user steps away. The factory-set sensing range for urinal models is between 15 to 30 inches, which can be adjusted if necessary. The module is compatible with urinals that have a flush volume of 0.5 or 1.0 gallons per flush (GPF) .
sloanrepair

Features

• Model Number: EBV-129-A-U
• Sloan Code Number: 3325451
• Compatibility: Designed for Sloan G2 and ECOS series urinal flushometers
• Flush Volume: Supports 0.5 GPF and 1.0 GPF urinals
• Sensor Range: Factory-set between 15" to 30"; adjustable as needed
• Power Source: Operates on four AA batteries (included)
• Installation: Easy retrofit for existing flushometers
• Maintenance: Features a visible red light for range adjustment and troubleshooting
