Safety & Instruction Manual

Cherne Single-Size Test-Ball Plugs are designed to test drain, vent and waste systems in every type of pipe. They also can be inserted through a test tee to seal out-of-round pipe. Cherne Industries is a global leader in pipe plug, blocking and testing.

Features:

• Single-Size Test-Ball® Plugs are designed to test drain, vent and waste systems in every type of pipe
• Natural rubber body provides excellent expansion and a great seal in round and out-of-round pipe
• Inflatable design can fit through test tees, sanitary tees, floor drains and other hard to access pipe openings
• Ideal for testing DWV plumbing systems at pressures up to 13 psi or with 30 ft of head pressure
• Utilizes a standard tire air fitting for easy connections
• Ring and chain assembly helps prevent the plug from being drawn into DWV systems during tests

Specifications:

• Weight: 3.5 oz.
• Maximum Back Pressure: 13 psi (0,9 bar)/30 ft. (9.1 M)
• Inflation Pressure: 40 psi (2,8 bar)
• Usage Range: 1.9 in. - 2.25 in. (48 - 57 mm)
• Deflated Length: 2.84 in.
• Deflated Diameter: 1.77 in.
• Nominal Size: 2 in. (50 mm)
• Inflation Thread: 1.77 in. (45 mm)
• Maximum Back Pressure Config: 13
• Deflated Diameter Config: 1.77
• Brand: Cherne
• Color: Black
• Product Type: Single-Size Plumbing Test-Ball
• Chain Eye Bolts: Ring and Chain
• Plug Type: Blocking

PAZ1A20500
